Table 13. Ports and connectors (continued)
Features Specifications
Security Noble wedge security slot
Audio
● Universal audio jack
● Noise reduction single microphone
Video
● HDMI 1.4b (UMA and discrete)
● VGA port
Network adapter One RJ-45 connector
Display
Table 14. Display specifications
Feature Specifications
Type
● 14 inch HD (1366 x 768) TN, Anti-glare, Ultra slim
● 14 inch FHD (1920 x 1080) IPS, Anti-glare (Optional)
Height (Active area)
205.6 mm (8.09 inch)
Width (Active area)
320.9 mm (12.63 inch)
Diagonal
355.6 mm (14 inch)
Luminance/Brightness (typical) 220 nits typ
Refresh rate
60 Hz
Horizontal viewing angle (min)
+/- 40 degrees
Vertical viewing angle (min)
+10/- 30 degrees
Keyboard
Table 15. Keyboard specifications
Feature Specifications
Number of keys
● 80 (U.S)
● 81 (Europe)
● 82 (Brazil)
● 84 (Japan)
Size Full sized
● X= 19.05 mm key pitch
● Y= 18.05 mm key pitch
Layout QWERTY/AZERTY/Kanji
14 System specifications
