Dell P98G - Power adapter; Display

Power adapter
Table 18. Power adapter specifications
Description Values
Type E5 90 W barrel E5 90 W Type-C E5 130 W Type-C
Diameter (connector) 7.4 mm Type-C connector Type-C connector
Input voltage 100 to 240 VAC 100 to 240 VAC 100 to 240 VAC
Input frequency 50 to 60 Hz 50 to 60 Hz 50 to 60 Hz
Input current (maximum) 1.6 A 1.5 A 1.8 A
Rated Output voltage/current 19.5 V/4.62 A
20V/4.5A(Continuos)
15V/3A(Continuos)
9.0V/3A(Continuos)
5.0V/3A(Continuos)
20V/6.5A(Continuos)
5.0V/1A(Continuos)
Temperature range:
Operating
0°C to 40°C (32°F to 104°F) 0°C to 40°C (32°F to 104°F) 0°C to 40°C (32°F to 104°F)
Storage
-40°C to 70°C (-40°F to
158°F)
-40°C to 70°C (-40°F to
158°F)
-40°C to 70°C (-40°F to
158°F
Display
Table 19. Display specifications
Description Values
Type
High definition (HD) Full High definition (FHD) Full High definition (FHD) Full High definition
(FHD)
Panel technology
WLED WLED WLED WLED
Luminance (typical)
220 nits 220 nits 220 nits 300 nits
Dimensions (Active
Area):
Height
173.95 mm (6.84 in.) 173.95 mm (6.84 in.) 173.95 mm (6.84 in.) 173.95 mm (6.84 in.)
Width
309.4 (12.18 in.) 309.4 mm (12.18 in.) 309.4 mm (12.18 in.) 309.4 mm (12.18 in.)
Diagonal
355.6 mm (14 in.) 355.6 mm (14 in.) 355.6 mm (14 in.) 355.6 mm (14 in.)
Native Resolution
1366x768 1920x1080 1920 x 1080 1920 x 1080
Megapixels
1.05 2.07 2.07 2.07
Color gamut NTSC 45% NTSC45% NTSC 45% NTSC 72%
Pixels per Inch (PPI)
112 157 157 157
Contrast Ratio (min)
400:1 700:1 700:1 700:1
Response Time (max)
25 ms 35 ms 35 ms 35 ms
Refresh Rate
60 Hz 60 Hz 60 Hz 60 Hz
System information 19
