Dell PowerConnect 8024 Configuration Guide

13 SCG1008 PowerConnect 8024, 8024F, M8024 and M8024-k Switch Configuration Guide for EqualLogic SANs
console(config)#ip http authentication local
console(config)#username admin password yourpassword privilege 15
console(config)#enable password yourpassword
3.9 Configure Jumbo Frames
console(config)#interface range tengigabitethernet all
console(config-if)#mtu 9216
console(config-if)#exit
3.10 Enable flow control
console(config)#flowcontrol
This operation may take a few minutes.
Management interfaces will not be available during this time.
Are you sure you want to continue? (y/n)y
3.11 Configure spanning tree portfast on edge ports
console(config)#interface range tengigabitethernet 1/0/1-16
console(config-if)#spanning-tree portfast
console(config-if)#exit
3.12 Configure port channel for LAG
These commands configure the switch interconnect as a LAG.
console(conf)#interface port-channel 1
console(conf-if-po1)#mtu 9216
console(conf-if-po1)#exit
3.13 Configure SFP+ ports for LAG (M8024-k)
Note: The commands in this section assign the four built-in external 10Gb SFP+ ports to the Port
Channel on the M8024-k. If you have the M8024 switch, skip this step and proceed to Section 3.14.
console(conf)#interface range tengigabitethernet 1/0/17-20

Dell PowerConnect 8024 Specifications

General

Switching Capacity	480 Gbps
Stackable	Yes
Device Type	Switch
Enclosure Type	Rack-mountable
Power Redundancy	Optional
Width	17.3 in
Height	1.7 in
Jumbo Frame Support	Yes
Ports	24 x 10 Gigabit SFP+
Management	Web-based GUI, Command Line Interface (CLI), SNMP
VLAN Support	Yes
Power Supply	Internal
Routing Protocol	Static routing
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z
Operating Temperature	0 to 45 °C
Storage Temperature	-20 to 70 °C
Relative Humidity	10% to 90% (non-condensing)
MAC Address Table Size	32, 000 entries
