Dell PowerEdge M610 Technical Guide 9
4.3 Internal Module View
A view of the internal module is shown in Figure 2. See the Opening and Closing the Blade section in
the Installing Blade Components chapter in the Dell PowerEdge Modular Systems Hardware Owner’s
Manual on Support.Dell.com/Manuals for more information.
Figure 2. Internal view
4.4 Cover Latch
The blade module includes a latch for the cover. See the Opening and Closing the Blade section in
the Installing Blade Components chapter in the Dell PowerEdge Modular Systems Hardware Owner’s
Manual on Support.Dell.com/Manuals for more information.
4.5 Security
The M610 offers a configurable client IP address range for clients connecting to iDRAC6. For
additional information regarding the PowerEdge M610 security features, see the Dell PowerEdge
Modular Systems Hardware Owner’s Manual on Support.Dell.com/Manuals.
4.5.1 TPM (Trusted Platform Module)
The TPM is used to generate/store keys, protect/authenticate passwords, and create/store digital
certificates. TPM can also be used to enable the BitLocker™ hard drive encryption feature in Windows
Server 2008. TPM is enabled through a BIOS option and uses HMAC-SHA1-160 for binding. TCM is
available in China.
4.5.2 Power Off Security
Through the BIOS, the front blade server USB ports and power button can be disabled so as to not
allow any control of the system from the front of the blade. The enclosure video can also be
restricted.
