Installing System Components 105
Installing the Integrated Storage Controller Card
CAUTION: Many repairs may only be done by a certified service technician. You
should only perform troubleshooting and simple repairs as authorized in your
product documentation, or as directed by the online or telephone service and
support team. Damage due to servicing that is not authorized by Dell is not covered
by your warranty. Read and follow the safety instructions that came with the
product.
1
Turn off the system, including any attached peripherals, and disconnect
the system from the electrical outlet.
2
Open the system. See "Opening the System" on page 78.
3
If installed, remove the expansion card. See "Removing an Expansion
Card" on page 96.
4
To install the integrated storage controller card:
a
Hold the card by its edges.
b
Align the card with the alignment guides.
c
Insert the card-edge connector firmly into the connector until the card
is fully seated.
5
Close the system. See "Opening and Closing the System" on page 78.
6
Reconnect the system to its electrical outlet and turn the system on,
including any attached peripherals.
R310HOM.book Page 105 Thursday, March 4, 2010 1:03 AM
