Dell PowerEdge R310 - Hard-Drive Status Indicators

18 About Your System
Hard-Drive Status Indicators
Figure 1-3. Hard-Drive Indicators
1 drive-status indicator (green
and amber)
2 drive-activity indicator (green)
Drive-Status Indicator Pattern (RAID Only) Condition
Blinks green two times per second Identify drive/preparing for removal
Off Drive ready for insertion or removal
NOTE: The drive status indicator remains
off until all hard drives are initialized after
system power is applied. Drives are not
ready for insertion or removal during this
time.
Blinks green, amber, and off Drive predicted failure
Blinks amber four times per second Drive failed
Blinks green slowly Drive rebuilding
Steady green Drive online
2
1
