76 Installing System Components
Figure 3-1. Inside the System
1 cooling shroud 2 power supply bays (2)
3 expansion-card risers (2) 4 heat sink/processor
5 memory modules (6) 6 optical drive
7 control panel board 8 display module
9 hard drives (4) 10 system cooling fans (5)
11 power supply shroud
2
1
11
3
4
5
6
9
10
7
8
