Installing System Components 81
Figure 3-4. Removing and Installing the Optical Drive
1 data cable 2 power cable
3 optical drive 4 release latch
5 metal standoffs (2) 6 notches (2)
7 metal standoffs with notches (2)
3
4
5
6
7
1
2
