98 Installing System Components
Figure 3-11. Installing and Removing an Expansion-Card Riser
1 expansion-card risers (2) 2 expansion-card slot
3 expansion-card riser sockets (2) 4 riser guide posts (2)
5 riser guides (2)
4
1
2
3
5
