Installing System Components 155
CAUTION: Do not pull on the cable to unseat the connector. Doing so can
damage the cable.
Figure 3-33. Removing and Installing the Front-Panel IO Module (Twelve–Hard-Drive
System)
1 front-panel IO cable 2 bracket
3 front-panel IO module 4 mounting screws (3)
4
2
3
1
