Dell PowerEdge R640 User Manual

Storage
The PowerEdge R640 provides scalable storage that allows you to adapt to your workload and operational requirements. With
comprehensive storage options, the PowerEdge R640 oers various internal and external storage controllers, drive types, and dierent
chassis and backplanes for varied numbers of drives. Features such as Express Flash PCIe SSDs, PERC H740p, and H840 RAID controllers
provide vastly accelerated performance compared to the previous technologies.
Storage controllers
The new PERC Controller oerings is a heavy leverage of previous generation PERC family. The Value Performance level controllers,
carried-over from previous generation to PowerEdge R640, are a high-end oering that drives Input/Output Operations Per Second (IOPs)
performance and enhance the SSD performance.
NOTE: On-board SATA ports (S140) are not accessible if mini PERC is installed.
Table 9. PERC series controller oerings
Performance Level Controller and Description
Entry
S140—SATA, NVMe
(SW RAID) SATA, NVMe
Value
HBA330—Internal, 12 Gbps SAS HBA—External
H330, 12 Gbps SAS HBA—External
Value Performance
H730P
Premium
Performance
H740P, H840
Supported drives
Table 10. Supported drives - SAS and SATA
Form
Factor
Type Spee
d
Rotational
Speed
Capacities
2.5 inches SATA,
SSD
6 Gb N/A 240 GB, 400 GB, 480 GB, 800 GB, 960 GB, 1.6 GB, 1.9 GB, 3.2 GB, 3.8 GB
SATA 6 Gb 7.2 K 1 TB, 2 TB
SAS 12 Gb 7.2 K 1 TB, 2 TB, 2 TB—SED FIPS
SAS,
SSD
12 Gb N/A 400 GB, 480 GB, 800 GB, 960 GB, 1.6 GB, 1.9 GB, 3.8 GB, 800 GB(SED FIPS), 1.6 GB—
SED FIPS
SAS 12 Gb 10 K
300 GB, 600 GB, 1.2 TB, 1.8 TB, 2.4 TB, 1.2 TB(SED FIPS), 2.4 TB—SED FIPS
6
22 Storage

Dell PowerEdge R640 Specifications

General

Tcase	77 °C
Stepping	U0
Scalability	2S
Processor code	SR3GJ
Processor cache	11 MB
Processor cores	8
Processor model	4108
System bus rate	- GT/s
Processor socket	LGA 3647 (Socket P)
Processor threads	16
Processor codename	Skylake
Execute Disable Bit	Yes
Number of QPI links	2
Processor frequency	1.8 GHz
Processor cache type	L3
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	76.0 x 56.5 mm
Processor boost frequency	3 GHz
Processor operating modes	64-bit
Embedded options available	No
Supported instruction sets	AVX, AVX 2.0, AVX-512, SSE4.2
Thermal Design Power (TDP)	85 W
Number of processors installed	1
Maximum number of PCI Express lanes	48
Memory types supported by processor	DDR4-SDRAM
Memory channels supported by processor	Hepta
Memory clock speeds supported by processor	2400 MHz
Maximum internal memory supported by processor	768 GB
On-board graphics card model	-
Memory slots	24
Internal memory	16 GB
Memory clock speed	- MHz
Maximum internal memory	3000 GB
HDD size	2.5 \
RAID levels	1, 5, 6, 10, 50, 60
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	DVD±RW
Total storage capacity	300 GB
Maximum storage capacity	- TB
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
PCI Express slots version	3.0
PCI Express x8 (Gen 3.x) slots	3
Chassis type	Rack (1U)
Operating system installed	Windows Server 2016 Datacenter
Compatible operating systems	Canonical Ubuntu LTS Citrix XenServer Microsoft Windows Server with Hyper-V Red Hat Enterprise Linux SUSE Linux Enterprise Server VMware ESXi
Power supply	750 W
Operating altitude	0 - 3048 m
Non-operating altitude	0 - 12000 m
Storage temperature (T-T)	-40 - 65 °C
Operating temperature (T-T)	10 - 30 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 80 %
Processor ARK ID	123544
Intel TSX-NI version	1.00

Weight and Dimensions

Depth	705.5 mm
Width	- mm
Height	42.8 mm
