6 Hardware and Initial Configuration
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\Maintenance Projects\Dell
Plasma\GSG\Plasma_UGHW&InitialConfiguration.fm
DELL CONFIDENTIAL – PRELIMINARY 3/6/13 - FOR PROOF ONLY
Switch Ports
Figure 1-1 shows the R1-2401device within the chassis. Only the switch
hardware is described in this guide.
Figure 1-1. R1-2401
Types of Ports
The following ports are found on the switch:
•
24 x 1 Gigabit/s Ethernet Ports.
These consist of:
–
8 external ports
—Connected to network (visible when the switch is in
the chassis)
–
16 internal ports
—Connected to blade servers (not visible when the
switch is in the chassis)
