Dell poweredge VRTX - Initial Configuration of the Switch

8 Hardware and Initial Configuration
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\Maintenance Projects\Dell
Plasma\GSG\Plasma_UGHW&InitialConfiguration.fm
DELL CONFIDENTIAL – PRELIMINARY 3/6/13 - FOR PROOF ONLY
Initial Configuration of the Switch
NOTE: Before proceeding further, read the latest documentation and release notes
for this product, which can be downloaded from the Dell Support website at
dell.com/support.
Healthy/Booted Blue On Switch is
functionally
normally.
Fault Amber
Blink 1 HZ
•On — Self-diagnosed fault
• Off
— Configuration error or
other CMC-detected fault
Switch has issued a
fault.
Booting Off On Boot in progress.
Identify Blue Blink
1 HZ
On CMC is identifying
the switch
Table 1-3. Port LEDs
LED Color
Link Off
— No Link
Solid green
— Link at 1G speed
Solid amber
— Link at 10/100M speed
Activity Off — No Link
Blinking green
— Traffic is being received/forward
Table 1-2. System LED’s
State of Switch Status LED Power LED (Green) Description
