The trace log may also contain CMC firmware-specific error codes that are related to the internal CMC firmware, not the
managed system’s operating system.
Troubleshooting Controller
To troubleshoot a controller:
1. In the left pane, click Chassis Overview → Storage → Controllers → Troubleshooting.
2. On the Controller Troubleshooting page, from the Actions drop-down list for the respective controller, select any
one of the following, and then click
Apply.
– Reset Configuration — Deletes the virtual disks and hots spares. However, the data on the disks are not
erased.
– Export TTY Log — The TTY debug log from the storage controller is exported to your local system.
NOTE: If there is pinned cache, the option to clear it will be present. If there is no pinned cache, this option
will not be displayed.
179
