20 Getting Started With Your System
Technical Specifications
Drives
PowerVault MD3600i Up to twelve 3.5-inch SAS hot-swappable
hard drives (3.0 Gbps and 6.0 Gbps)
PowerVault MD3620i Up to twenty four 2.5-inch SAS
hot-swappable hard drives (3.0 Gbps and
6.0 Gbps)
RAID Controller Modules
RAID controller modules
• One or two hot-swappable modules
with temperature sensors
• 2 GB of cache per controller
Back-Panel Connectors (Per RAID Controller Module)
iSCSI connectors Two 10 GB iSCSI IN connectors to
connect hosts
SAS expansion connector One SAS OUT port for expansion to an
additional PowerVault MD12xx enclosure.
NOTE: SAS connectors are SFF-8088 compliant.
Serial connector One 6-pin mini-DIN connector
NOTE: For technical support use only.
Management Ethernet connector One 100/1000 Base-T port Ethernet for
out-of-band management of the enclosure
Expansion
PowerVault MD36xxi Supports a maximum of 96 hard drives with
any combination of PowerVault MD1200 or
PowerVault MD1220 expansion enclosures.
NOTE: You cannot use more than seven
expansion enclosures.
Redundant path connectivity provides
redundant data paths to each hard drive.
