Dell PowerVault MD3860f - Physical-Disk LED Indicators

Item Indicator or Connector Icon Description
Off Indicates that you cannot
remove the power supply
module from the system.
6 Service action required
indicator
The service action required indicator lights amber
when there is a fault in the power supply module.
7 AC power indicator
Green Indicates that AC output
voltage is within the limit.
Off Indicates that AC output
voltage is not within the
limit.
Physical-Disk LED Indicators
Figure 7. Physical-Disk LED Indicators
13
