Dell Precision
™
490 Workstation
Up to two Dual-Core Intel
®
Xeon
®
64-bit processors with up to 1066MHz front side bus and 2MB L2 cache per core, with XD, HT, VT and EIST; All Intel
®
Xeon
®
processors support 64-bit computing with Intel EM64T
Dell recommends Microsoft
®
Windows
®
XP Professional for Business
Genuine Windows XP Professional; Genuine Windows XP Professional x64 Edition;
Red Hat
®
Enterprise Linux WS v.4 (IA32); Red Hat Enterprise Linux WS v.4 (Intel EM64T)
Intel
®
5000X chipset
Up to 32GB
1
quad-channel
2
DDR2 Fully Buffered DIMM (FBD) 533MHz ECC memory; Eight DIMM slots
4MB flash memory for system BIOS; SMBIOS 2.3.1 support
Support for PCI Express x16 graphics cards up to 150 watts and with up to 512MB graphics memory including: nVIDIA
®
Quadro
®
FX 4500; nVIDIA
Quadro FX 3500; ATI FireGL 7200; nVIDIA Quadro FX550; ATI
™
FireGL
™
V3400; nVIDIA Quadro NVS 285; All graphics cards support dual monitor
configurations
SATA 3.0Gb/s 7200RPM with 8MB DataBurst Cache™ up to 250GB
3
; SATA 3.0Gb/s 10K RPM with 16MB DataBurst Cache™ up to 500 GB
3
; SATA
10K RPM with 8MB DataBurst Cache™ up to 160GB
3
; SAS 10K RPM up to 300GB
3
; SAS 15K RPM up to 146GB
3
; Chassis supports up to three
internal drives (1.5TB
3
storage maximum)
Integrated SATA 3.0Gb/s controller with support for RAID 0, 1, and 5; SAS RAID 0, 1 with optional SAS 5i/r PCI-E card; SAS RAID 0, 1, 5, 10 with
optional PERC 5/i PCI-e card
Integrated Broadcom
®
5752 Gigabit
4
Ethernet controller
Integrated High Definition Audio (Rev 1.0 Specification) with Sigmatel STAC9200 High Definition Audio CODEC and Intel ESB2’s AC97/ High
Definition digital controller
Eight USB 2.0: two on front panel, five on back panel, one internal on motherboard; Two serial; One parallel; Two PS/2; One RJ-45; Stereo line-in
and headphone line-out on back panel; Microphone and headphone connector on front panel
IEEE 1394a connector available on front panel with add-in card
Desktop orientation with feet: (WxHxD) 17.64" x 6.73" x 18.54" (maximum including badge); 44.8 cm x 17.1 cm x 47.1 cm (maximum including badge)
Mini-Tower orientation with feet: (WxHxD) 6.73" x 17.64" x 18.54"; 17.1 cm x 44.8 cm x 47.1 cm (maximum including badge)
Two internal 3.5" HDD bays; Two external 5.25" optical bays, one of which can accommodate a third HDD in mini-tower orientation.
One external 3.5" flex bay for floppy or media card reader, one of which can accommodate a third HDD in desktop orientation; One PCI-e x16
graphics slot, Two PCI-e x8 slots wired as x4, Two PCI-X 64bit/100MHz slots with support for 3.3v or universal cards, One PCI 32bit/33Mhz slot;
750 watts Power Factor Correcting (PFC) power supply
Performance flat panel displays, Dell UltraSharp™ widescreen and standard flat panel displays from 17" viewable to 24" viewable;
Analog flat panel displays and CRT monitors also available
Dell Enhanced QuietKey USB; Enhanced Multimedia USB; Smart Card keyboard USB
Dell USB two-button mouse and Dell USB optical two-button scroll mouse
Internal chassis speaker; Dell two and three piece stereo system; Dell sound bar available for all flat panel displays
USB Floppy Drive; CD-ROM, CDRW
5
; CD-RW/DVD Combo; DVD-ROM
5
; DVD+/-RW
5
; and USB media card reader and Dell USB Memory Key up to
512MB
6
Dell 56K
7
v.92 Data/Fax PCI modem
Trusted Platform Module 1.2 (TPM 1.2); Chassis intrusion switch; Setup/BIOS Password; I/O Interface Security
TCO99, Blue Angel, Green PC, Energy Star, BSMI, C-TICK, CE, FCC, IRAM, NEMKO, NFPA 99, SABBS, SASO, TCO, TUV, UL, VCCI, USB 2.0; WEEE
Environmentally conscious design is RoHS Compliant
10
/Lead Free
11
3-Year Limited Warranty
8
with 3 years standard Next Business Day (NBD) onsite
9
parts replacement and 3 years NBD onsite
9
labor (US Only)
3-Year Same Business Day 4 hour On-site Service
9
– 5 days a week, M-F 10 hours a day (8-6PM)
3-Year Same Business Day 4 hour On-site Service
9
– 7 days a week, 24 hours a day
3 & 4-year Gold Technical Support, expert support via phone, e-mail and online chat - 7 days a week, 24 hours a day
SYSTEM
Processors
Operating systems
Chipset
Memory
Flash BIOS
Graphics
Hard drives
Hard drive controller
Network controller
Audio controller
Standard I/O ports
Optional I/O
CHASSIS
Dual-orientation desktop
PERIPHERALS
Monitors
Keyboard
Mouse
Optional Speakers
STORAGE DEVICES
Optional Removable Storage
Optional Modem
SECURITY
Software
ENVIRONMENTAL & REGULATORY
Standards
Lead Free
SERVICE & SUPPORT
Base
Recommended
NOTE: Some applications and peripherals are not compatible with a 64-bit operating system environment. Be sure to verify with all of your current application vendors that your full application suite is compatible before purchasing a Dell
Precision workstation with a 64-bit operating system.
Dell PCs use genuine Microsoft Windows. www.microsoft.com/piracy/howtotell. Dell’s Terms and Conditions of Sales and Service apply and are available upon request. Dell cannot be held responsible for errors in typography or
photography. 1 The total amount of usable memory available will be less, depending on the actual system configuration. To utilize more than 4GB of memory requires a 64-bit OS. To expand memory to more than 32GB requires a Dell Precision
490 1KW system with memory risers. 2 Quad-channel memory requires 4 each of the same capacity memory DIMMs 3 For hard drives, one GB means 1 billon bytes and one TB equals one trillion bytes; actual capacity varies with preloaded
material and operating environment and will be less. 4 This term does not connote an actual operating speed of 1 GB/sec. For high speed transmission, connection to a Gigabit Ethernet server and network infrastructure is required.
5 Discs burned with this drive may not be compatible with some existing drives and players; using DVD+R media provides maximum compatibility. 6 For writeable storage devices, MB means 1 million bytes; total accessible capacity
varies depending on operating environment. 7 Download speeds are limited to 53Kbps. Upload speeds are less (about 30Kbps). Speeds can vary by line condition and modem manufacturer. Analog phone line and service required.
8 For a complete copy of our guarantees and limited warranties, please write Dell U.S.A. L.P., Attention: Warranties, One Dell Way, Round Rock, TX 78682. For more information, visit http://www.dell.com/us/en/gen/misc/policy_010_policy.htm.
9 Service may be provided by third-party. Technician will be dispatched if necessary following phone-based troubleshooting. Subject to parts availability, geographical restrictions and terms of service contract. Service timing dependent
upon time of day call placed to Dell. U.S. only. 10 Meets the requirements of the EU Directive on the Restriction of the use of certain Hazardous Substances dated January 27, 2003. 11 Per the EU Directive on the Restriction of the use of certain
Hazardous Substances directive, this system (chassis and factory installed components) or configuration contains less than 0.1% lead by weight. Dell, the Dell logo, Dell Precision, OpenManage, and UltraSharp are trademarks of Dell Inc. Intel
and Xeon are registered trademarks of Intel Corporation. Microsoft and Windows are registered trademarks or trademarks of Microsoft Corporation in the U.S. and other countries. Dell Inc. disclaims any proprietary interest in trademarks
and trade names other than its own. © Copyright 2006 Dell Inc. All rights reserved. Legal ad# 69971813
*Dual-core performance gains (Woodcrest): 45% performance gain based on the SPEC CPU2000 (integer-speed base) benchmark test performed by Dell Labs in January 2006 on the Dell Precision 690 with two Intel Xeon 5150 2.66GHz
processors with dual-core, 4MB L2 cache and 1333MHz FSB (No HT available), 8GB DDR2 533 ECC FBD memory, 160GB SATA 7200RPM HDD, Microsoft Windows XP Pro SP2 as compared to the Dell Precision 670 with two Intel Xeon 3.8GHz
processors with 2x 2MB L2 cache & 800MHz FSB (HT off), 2GB DDR2 ECC memory, 160GB SATA 7200RPM HDD, Microsoft Windows XP Pro SP2. Actual performance will vary based on configuration, usage and manufacturing variability.
155% performance gain based on the SPEC CPU2000 (integer-rate base) benchmark test performed by Dell Labs in January 2006 on the Dell Precision 690 with two Intel Xeon 5150 2.66GHz processors with dual-core, 4MB L2 cache and
1333MHz FSB (No HT available), 8GB DDR2 533 ECC FBD memory, 160GB SATA 7200RPM HDD, Microsoft Windows XP Pro SP2 as compared to the Dell Precision 670 with two Intel Xeon 3.8GHz processors with 2x 2MB L2 cache and
800MHz FSB (HT off), 2GB DDR2 ECC memory, 160GB SATA 7200RPM HDD, Microsoft Windows XP Pro SP2. Actual performance will vary based on configuration, usage and manufacturing variability
