Table 23. GPU—Discrete (continued)
Controller Memory size Memory type
NVIDIA RTX A2000 Laptop 8 GB GDDR6
Multiple display support matrix
The following table lists the multi-monitor support matrix supported by your Precision 5570.
Table 24. Integrated - Multiple display support matrix
Video ports on Integrated Graphics Card
● One USB 3.2 Gen 2 Type-C port with DisplayPort Alt
Mode
● Two Thunderbolt 4 ports with Power Delivery
Video port on Option Video module
● One USB 3.2 Gen 2 Type-C port with DisplayPort Alt
Mode
● Two Thunderbolt 4 ports with Power Delivery
Number of displays Three 4K external displays, one 5K or one 8K and above
displays using the Thunderbolt 4 (USB-C) ports available on
your Precision 5570
Table 25. Discrete - Multiple display support matrix
Graphics Card NVIDIA RTX A1000 Laptop NVIDIA RTX A2000 Laptop
Memory 4 GB GDDR6 8 GB GDDR6
Video Ports on system
● One USB 3.2 Gen 2 Type-C port with
DisplayPort Alt Mode
● Two Thunderbolt 4 ports with Power
Delivery
● One USB 3.2 Gen 2 Type-C port with
DisplayPort Alt Mode
● Two Thunderbolt 4 ports with Power
Delivery
Max Displays (direct connect)
4 4
Max Displays (DP multi-stream) 1 1
Number of displays 1 1
Supported Resolution 4096x2304 @60 Hz 4096x2304 @60 Hz
Total Power 35 W to 95 W 35 W to 95 W
Hardware security
The following table lists the hardware security of your Precision 5570.
Table 26. Hardware security
Hardware security options
NIST 800-147 protocol
Trusted Platform Module (TPM) 2.0 FIPS-140-2 Certified/TCG Certified
Touch Fingerprint Reader (in Power Button) with Control Vault 3.0 Advanced Authentication with FIPS 140-2 Level 3
Certification (Optional)
Face IR camera (Windows Hello compliant) with ExpressSign-in 1.0 (Proximity Sensor)
Face IR camera (Windows Hello compliant) with ExpressSign-in 2.0 (Camera Sensing) (Optional)
Intel vPro Technology (iAMT 12) (optional, requires Intel WiFi Link WLAN and a vPro compatible processor)
20 Specifications of Precision 5570
