Supports USB4 Gen 3x2, DisplayPort 1.4a and Thunderbolt 4. Enables you to connect to an external display using a display
adapter. Provides data transfer rates up to 40 Gbps for USB4 Gen 3x2 Thunderbolt 4. Supports Power Delivery that enables
two-way power supply between devices. Provides up to 5 V/ 3 A power output that enables faster charging.
NOTE: A USB Type-C to DisplayPort adapter (sold separately) is required to connect a DisplayPort device.
NOTE: A 40 Gbps-certified cable is required to achieve the maximum performance of 40 Gbps.
NOTE: Thunderbolt 4 supports two 4K displays or one 8K display.
NOTE: USB4 is backward compatible with USB 3.2, USB 2.0, and Thunderbolt 3.
NOTE: You can connect a Dell docking station to the Thunderbolt 4 ports. For more information, see the knowledge
base article 000124295 at www.dell.com/support.
3. Left woofer
Enhances low-frequency audio output.
Top
1. Microphones (2)
Provide digital sound input for audio recording, voice calls, and so on.
2. Power button with fingerprint reader
Press to turn on the computer if it is turned off, in sleep state, or in hibernate state.
When the computer is turned on, press the power button to put the computer into sleep state; press and hold the power
button for 10 seconds to force shut-down the computer.
Place your finger on the power button to log in with the fingerprint reader.
NOTE:
You can customize power-button behavior in Windows. For more information, see Me and My Dell at
www.dell.com/support/manuals.
NOTE: In Windows, Windows Hello supports a defined number of fingerprints per account. For more information about
configuring your fingerprint reader with Windows Hello, search in the Knowledge Base Resource at www.dell.com/
support.
3. Right speaker
Views of Precision 5570
7
