Dell Precision 5750 External Display Connection Guide

● Connect up to three external displays using a USB-C docking station:
Discrete graphics
Connecting external displays to Precision 5750 with discrete graphics
If you have a discrete graphics card installed in your computer, such as the NVIDIA Quadro RTX3000, you can connect up to
four external displays or two 8K displays.
NOTE: Direct Graphics Controller Direct Output Mode, needs to be enabled to connect four external displays.
NOTE: When connecting a display indirectly using a adapter or docking station, it is recommended that you connect the
display to the docking station first, then connect the docking station to the Thunderbolt 3 (USB-C) port on your computer.
NOTE: The devices connected to the ports on the left side of the computer have priority over the ports on the right. While
connecting external displays, it is recommended that you connect the displays to the left ports.
If you have a NVIDIA Quadro RTX3000 discrete card with Direct Graphics Controller Direct Output Mode disabled, the maximum
number of external displays supported is the same as the integrated graphics option.
10
Connect external displays

Dell Precision 5750 Specifications

General

Memory	Up to 64GB DDR4 2933MHz
Processor	10th Gen Intel Core i5/i7/i9 or Xeon
Display	17.0-inch UHD+ (3840 x 2400) InfinityEdge Touch Anti-Reflective 500-Nit
Graphics	NVIDIA Quadro RTX 3000/5000
Storage	Up to 4TB PCIe NVMe SSD
Operating System	Windows 10 Pro
Weight	Starting at 4.7 lbs (2.13 kg)
Ports	4 x Thunderbolt 3
Wireless	Intel Wi-Fi 6 AX201, Bluetooth 5.1
Camera	720p HD Webcam
Audio	Stereo speakers with Waves MaxxAudio Pro, dual microphone array
Battery	6-Cell 97 WHr
Dimensions	14.74" (374.48 mm) x 9.77" (248.08 mm)
