23" LCD Color Monitor Dell SP2309Wc
34
Disconnect connector
remarked in green.
Install:
Note: Make LVDS
connector’s metal side
adown
Remove the Power
Board, Main Board:
Remove the screws by
torque B and disconnect
connector remarked in
green.
USB
cable
