23" LCD Color Monitor Dell SP2309Wc
33
Remove shield:
Remove the screws by
Torque B or by manual, and
disconnect connector
remarked in green.
then remove the shield.
Remove the screws and
remove the main frame by
manual or torque =
3kgF.Cm.
Key board
cable
