Electrical
Model ST2210/ST2310/ST2410
Video input signals
Analog RGB, 0.7 Volts +/- 5%, positive polarity at 75 ohm input impedance
Digital DVI-D TMDS, 600mV for each differential line, positive polarity at 50 ohm input
impedance
HDMI, 600mV for each differential line, 100 ohm input impedance per differential pair
Synchronization input signals
Separate horizontal and vertical synchronizations, polarity-free TTL level, SOG (Composite
SYNC on green)
AC input voltage/frequency/current 100 to 240 VAC/50 or 60 Hz + 3 Hz/2.0A (Max.)
Inrush iso surge current
120 V: 30 A (Max.)
240 V: 60 A (Max.)
Physical Characteristics
Model ST2210 ST2310 ST2410
Connector type
D-sub: Blue connector •
DVI-D: White connector•
HDMI•
D-sub: Blue connector •
DVI-D: White connector•
HDMI•
D-sub: Blue connector •
DVI-D: White connector•
HDMI•
Signal cable type
D-sub: Detachable, Analog, 15 pin,
shipped attached to the monitor
•
DVI-D•
HDMI•
D-sub: Detachable, Analog, 15 pin,
shipped attached to the monitor
•
DVI-D•
HDMI•
D-sub: Detachable, Analog, 15 pin,
shipped attached to the monitor
•
DVI-D•
HDMI•
Dimensions (with stand)
Height 383.55 mm (15.10 inches) 403.15 mm (15.87 inches) 413.79 mm (16.29 inches)
Width 530.97 mm (20.90 inches) 563.52 mm (22.19 inches) 584.86 mm (23.03 inches)
Depth 217.00 mm (8.54 inches) 217.00 mm (8.54 inches) 217.00 mm (8.54 inches)
Dimensions (without stand)
Height 321.69 mm (12.66 inches) 341.03 mm (13.43 inches) 352.51 mm (13.88 inches)
Width 530.97 mm (20.90 inches) 563.52 mm (22.19 inches) 584.86 mm (23.03 inches)
Depth 81.74 mm (3.22 inches) 84.24 mm (3.32 inches) 84.24 mm (3.32 inches)
Stand dimensions
Height 129.70 mm ( 5.11 inches) 129.70 mm ( 5.11 inches) 129.70 mm ( 5.11 inches)
Width 217.00 mm (8.54 inches) 217.00 mm (8.54 inches) 217.00 mm (8.54 inches)
Depth 217.00 mm (8.54 inches) 217.00 mm (8.54 inches) 217.00 mm (8.54 inches)
Page 11 of 13
