Active-off mode Inactive Inactive Blanked Amber Less than 1 W
Switch off - - - Off Less than 0.5 W
ST2410
VESA Modes Horizontal
Sync
Vertical Sync Video Power
Indicator
Power Consumption
Normal operation Active Active Active White 30 W (maximum)
23 W (typical)
Active-off mode Inactive Inactive Blanked Amber Less than 1 W
Switch off - - - Off Less than 0.5 W
NOTE: This monitor is ENERGY STAR
®
-compliant.
NOTE: Zero power consumption in OFF mode can only be achieved by disconnecting the main cable from the
monitor.
Pin Assignments
VGA Connector
Pin Number 15-pin Side of the Connected Signal Cable
1 Video-Red
2 Video-Green
3 Video-Blue
4 GND
Page 6 of 13
