24 | About your monitor
Universal Serial Bus (USB)
This section gives you information about the USB ports available on your monitor.
NOTE: Up to 2 A on USB downstream port (port with battery icon)
with BC 1.2 compliance devices; up to 0.9 A on the other USB downstream
ports; up to 3 A on USB-C downstream port (port with
icon) with 5 V /
3 A compliance devices.
Your monitor has the following USB ports:
• 1 USB-C upstream port (data only) - at bottom.
• 1 USB-C downstream port - at Quick Access.
• 3 super speed USB 10 Gbps (USB 3.2 Gen 2) Type-A downstream ports- 2 at
bottom, 1 at Quick Access.
Power Charging Port - the ports with battery icon supports fast current
charging capability if the device is BC 1.2 compatible. The USB-C downstream
port with icon supports fast current charging capability if the device is 5 V / 3
A compatible.
NOTE: The monitor’s USB ports work only when the monitor is on or in
Standby Mode. On in Standby Mode, if the USB cable (A to C or C to C) is
plugged in, the USB ports can work normally. Otherwise, follow the OSD
setting of Other USB Charging, if the setting is “On in Standby Mode”
then USB work normally, otherwise USB is disabled. If you turn off the
monitor and then turn it on, the attached peripherals may take a few
seconds to resume normal functionality.
Super speed USB 10 Gbps (USB 3.2 Gen 2) device
Transfer speed Data rate Maximum power consumption (each port)
Super speed+ 10 Gbps 4.5 W
Hi-Speed * 480 Mbps 4.5 W
Full speed * 12 Mbps 4.5 W
* Device speed when High Resolution is selected.
USB-C upstream
• Data Super Speed+ 10Gbps (USB 3.2 Gen 2)
