Setting up the monitor │ 37
Setting up the monitor
Attaching the stand
NOTE: The stand is not installed at the factory when shipped.
NOTE: The following instructions are applicable only for the stand that
was shipped with your monitor. If you are attaching a stand that you
purchased from any other source, follow the setup instructions that
were included with the stand.
To attach the monitor stand:
1. R
emove the stand riser and stand base from the packaging cushion.
NOTE: The image is for the purpose of illustration only. The appearance
of the package cushion may vary.
2. Inse
rt the stand base blocks fully into the stand slot.
3. L
ift the screw handle and turn the screw clockwise.
4. A
fter fully tightening the screw, fold the screw handle flat within the recess.
