Installing the display panel hinges
1. Install the display panel hinges on the display assembly.
2. Install the screws that secure the display panel hinges.
3. Install the:
a. display bezel
b. display assembly
c. system fan
d. LED board
e. WLAN card
f. battery
g. back cover
4. Follow the procedure in After working inside your computer
Removing the camera
1. Follow the procedure in Before working inside your computer.
2. Remove the :
a. back cover
b. battery
c. WLAN card
d. LED board
e. system fan
f. display assembly
g. display bezel
3. To remove the camera:
a. Disconnect the camera connector cable. [1]
b. Lift to remove the camera from the computer. [2]
42

Dell Vostro 15-5568 Specifications

General

Processor	Intel Core i5-7200U
RAM	8GB DDR4
Graphics	Intel HD Graphics 620
Operating System	Windows 10 Pro
Wireless	802.11ac Wi-Fi, Bluetooth 4.2
Display	15.6-inch FHD (1920x1080)
Battery	3-cell 42Whr
Weight	1.98 kg
Ports	2 x USB 3.0, 1 x USB 2.0, HDMI, SD card reader, headphone/microphone combo jack
Dimensions	380 x 252 mm
