About Your Computer 33
Bottom View
LEFT SPEAKER — To adjust the volume of the integrated speaker, press the volume
control buttons or the mute button.
CONSUMER IR SENSOR — Receives the signal from the Dell travel remote controller
for basic multimedia navigation control.
1 left speaker 2 consumer IR sensor
3 memory module/coin-cell battery
cover
4 right speaker
5 Mini-Card cover 6 battery
7 battery charge/health gauge 8 battery release latches (2)
9 air vents 10 hard drive
5
10
7
6
8
9
