Table 5. Audio
Feature Specification
Controller ALC3661-CG (Realtek)
Speaker single 4-ohms, 2.5 W AVG speakers
Internal speaker amplifier up to 3 W per channel
Internal microphone support single digital microphone (optional)
Table 6. Communications
Feature Specification
Network adapter Intel 10/100/1000 Mbps Ethernet LAN
Wireless half mini-card (Wi-Fi b/g/n supporting Wi-Fi display)
(optional)
Table 7. Displays
Feature Specification
Type 19.5 inch HD+ WLED
Maximum resolution 1600 x 900
Refresh rate 60 Hz
Brightness Brightness up/down buttons
Operating angle 178 horizontal / 178 vertical
Pixel pitch 0.2652 mm
Controls on-screen controls
Dimensions:
Height 249.08 mm (9.81 inches)
Width 442.80 mm (17.43 inches)
Diagonal 508.00 mm (20.00 inches)
Table 8. Drives
Feature Specification
Hard drive one 2.5-inch SATA drive
Optical drive (optional) one DVD-ROM, DVD+/- RW
Table 9. Ports and Connectors
Feature Specification
Audio one audio combo connector
Network adapter one RJ-45 connector
41
