Dell Vostro 3670 - Installing WLAN Card

Installing WLAN Card
1 Insert the WLAN card to the connector on the system board [1].
2 Connect the WLAN cables to the connectors on the WLAN card [2].
3 Place the plastic tab on the WLAN card [3] and tighten one (M2x3.5) screw to secure the WLAN card to the system board [4].
Removing and installing components
39
