Dell Vostro 3670 - Power, Cooling, and Core Component Servicing

4 Install the:
a Cover
5 Follow the procedure in After working inside your computer.
Memory modules
Removing memory module
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a Cover
3 To remove the memory module:
a Push the memory module retention tabs on both sides of the memory module.
b Lift the memory module from the memory module connector on the system board.
40
Removing and installing components
