Installing The System Board
1. Carefully place the system board into the computer.
2. Slide the system board towards the back of the computer.
3. Replace and tighten the eight screws that secure the system board to the computer.
4. Thread and connect all the cables to the system board.
5. Install the
heatsink and processor.
6. Install the
memory.
7. Install the
video card.
8. Install the
video card holder.
9. Install the
front bezel.
10. Replace the
computer cover.
11. Follow the procedures in
After Working Inside Your Computer.
Related tasks
Removing System Board
