Replacing the Theater Lighting Unit 21
3
Disconnect the
theater lighting card connector.
4
Remove the screw securing the theater lighting card to the chassis and lift
the card out of the slot.
5
Replace the theater lighting card in its slot and tighten the screw.
6
Replace the computer cover (see "Replacing the Computer Cover" on
page 17).
1 theater lighting card 2 theater lighting card
connector
