Figure 27
Figure 27a
Figure 27b
Figure 27c
Figure 27d
C
A
B
REMOVING THE DOOR
The oven door can easily be removed
as follows:
– Open the door to the full extent (fig.
27a).
– Open the lever A completely on the
left and right hinges (fig. 27b).
– Hold the door as shown in fig. 27.
– Gently close the door until left and
right hinge levers A are hooked to
part B of the door (fig. 27c).
– Withdraw the hinge hooks from their
location following arrow C (fig. 27d).
– Rest the door on a soft surface.
