18
The following instructions will help you set up your air conditioning unit as efficiently as possible.
AIR CONDITIONING WITHOUT INSTALLATION
FOR INSTANT TEMPORARY USAGE
With just a few simple operations, Pinguino will
restore comfortable conditions in your room:
• Fix the exhaust hose to the coupling
on the back of the unit as shown in figu-
re A.
7
20
•With a double casement window, use the
suckers provided to hold the two hal-
ves of the window together (fig. C).
22
• Fix the window attachment to the end
of the hose .
• Place the unit near a window French win-
dow or door.
• Open the window, French window or door
slightly and place the window attachment
as shown in figure B.
21
21
20
Setting up
B
C
