Setting up
AIR CONDITIONING WITH INSTALLATION
For more efficient use Pinguino can also be
semi-permanently installed
• Fit the flange supplied to the hole.
• Fix the hose to the coupling on the
back of the unit (figure A).
• Attach the end of the hose to the flan-
ge as shown in the figure E.
19
20
20
19
To install, proceed as follows:
• Make a hole in a outside wall or through
the glass of a window. Check the height
and dimensions given in figure D
When the hose is not attached, close the
hole with the bung on the flange .
NOTE:
When the unit is installed semi-permanently,
we recommend leaving a door slightly open
(1 cm is enough) to ensure an adequate
exchange of air.
19
20
in a window
pane
in the wall: for
optimum results,
insulate the sec-
tion of the wall
with suitable
insu-lating
material.
in the
wood sill of
a window
D
E
