Delphi GT 280 - Connection System - Completed Assembly

Assembly Manual
4 Way GT 280 Sealed Connection System
GT 2.8 Terminal System (Sealed)
© Delphi Corporation. All Rights Reserved
www.delphi.com
Assembly Manual - 33278895
22
STEP 3b – Lock CPA to Full-Stage Position (Optional Component)
CONNECTION SYSTEM – COMPLETED
ASSEMBLY
CPA IS NOW IN FULL-STAGE POSITION
VERIFY AUDIBLE CLICK
CPA IS FLUSH WITH THE
CONNECTOR LOCK
