AV28 PWM minimum value or Binary On Delay Depends on OP3 configuration
AV29
PWM maximum value or Time
Proportioned Heating Controller Limit
Depends on OP3 configuration
Sequence of Operation
The selected heating outputs will be operated according to their type and the controller stage that they
are associated with. There can be up to three stages of heating, depending on the heating type and
configuration of the outputs. Also, Outputs 1 to 3 may be defined as Time Proportioned instead.
8. H
UMIDITY – [Application (AV12) = 6]
Function: Simple control of a humidifier.
DNT-TH103 I/O (Outputs 1 to 3 are Triacs)
Input AI1 Input AI2 Input AI3 Remote AV5 Output 1 Output 2 Output 3
Room Temp.
(Optional)
Room
Humidity
Optional OAT Humidifier MUX MUX
DNT-H121 I/O (Outputs 1 & 2 are Analog, and Output 3 is a Triac)
Input AI1 Input AI2 Input AI3 Remote AV5 Output 1 Output 2 Output 3
Room Temp.
(Optional)
Room
Humidity
Optional OAT Humidifier MUX MUX
Setup Parameters
Setup Variable Function Notes
AV24 PWM minimum value or Binary On Delay Depends on OP1 configuration
AV25 PWM maximum value Depends on OP1 configuration
AV26 PWM minimum value or Binary On Delay Depends on OP2 configuration
AV27 PWM maximum value Depends on OP2 configuration
AV28 PWM minimum value or Binary On Delay Depends on OP3 configuration
AV29 PWM maximum value Depends on OP4 configuration
Sequence of Operation
Input 3 represents the built-in humidity sensor and becomes the input to the internal controller. The
adjustable room setpoint (AV6) becomes the humidity setpoint. And the controller proportional band is
used for humidity control, now in units of percent. Output 1 (via AV1) will operate according to its
selected output type and the value of the controller output, typically turning O
N when the humidity is
low and O
FF when the setpoint value has been reached.
OUTPUT FUNCTIONS & TYPES
Regardless of model, any triac outputs are capable of switching up to 24 VAC at a maximum of 0.5 A
each, and may be configured for any of a number of output functions and types. Only the DNT-T221
supports two
0-10v outputs, up to a maximum of 20 mA each. Not all applications support all the options listed.
Function
FUNCTIONS
Description LCD Code
MUX
The associated output will be MUXed and not controlled by the
local algorithm, or not used at all.
0

Heating The associated output is connected to 1st stage heating. 10

