Delta Controls
Document Edition 4.1 Page 37 of 41
the Application Controller to represent the 10K Thermistor value on a BACstat with a LINKnet
device address of 5.
With V3.22 or higher loaded in the Application Controller, AV objects may be created in a similar
fashion to the AI objects, which map to corresponding AV objects in the BACstat. You can then use
these in GCL+ programming as well. With V3.21, mapped AV objects are not supported.
Software & Programming
OBJECTS
The following is a list of predefined objects that reside in the BACstat II products that cannot be
created or deleted. When connected to an MS/TP network, these objects are readily accessible over
the network.
Object Name Description Default Value
AIx01
Temperature Input 1 (10K Thermistor Value) N/A
AIx02 Input 2 * Input 2 (Available Input) N/A
AIx03
Humidity Input 3 (Humidity on DNT-H103 DNT-H121) N/A
Input 3 * Input 3 (Extra Input on DNT-T103 DNT-T221) N/A
BO1 Output 1 * Output 1 on DNT-T103 N/A
BO2 Output 2 * Output 2 on DNT-T103 N/A
BO3 Output 3 * Output 3 on DNT-T103 N/A
AO1 Output 1 * Output 1 on DNT-T221 N/A
AO2 Output 2 * Output 2 on DNT-T221 N/A
BO3 Output 3 * Output 3 on DNT-T221 N/A
AVx04
KeyPress KeyPress Value N/A
AVx06
Day Setpoint Room Setpoint ºC = 21; ºF = 71; % = 30
AVx07
Day Minimum Minimum Adjustable Day Setpoint ºC = 18; ºF = 65; % = 20
AVx08
Day Maximum Maximum Adjustable Day Setpoint ºC = 25; ºF = 77; % = 55
AVx09
Day Differential Room Setpoint Differential ºC = ±0.5; ºF = ±1, % = ±2.5
AVx10
Night Heat Setpoint Night Setpoint for Heating (or Humidity) ºC = 16; ºF = 60; % = 30
AVx11
Night Cool Setpoint Night Setpoint for Cooling ºC = 30; ºF = 86; % = 30
AVx15
Display Code Local Display & Button Handling 1237
AVx16
AI1 Calibration Input 1 Calibration (Temperature) 0.0
AVx17 AI2 Calibration Input 2 Calibration (MUXed IP) 0.0
AVx18
AI3 Calibration Input 3 Calibration (Humidity) 0.0
AVx30
Baud Rate Network Baud Rate *
AVx31
PIN PIN (4-Bit Configuration Access Code) 1011
* Names are user settable (to a maximum of 32 characters), and only on outputs when they are controlled remotely (i.e.,
MUXed).
These are the typical objects that may be commanded on the fly by a user or from GCL++, and also include the
Outputs when they are MUXed.
GCL++ Programming
All GCL+ programming for BACstats on a LINKnet network is written in the Application Controller
that the BACstats are connected to, using the mapped objects resident in the Application Controller.
The LCD object is used for display and button handling. The mapped AI objects are used for reading
values. And with at least V3.22 firmware on the Application Controller, the mapped AV objects are
used for outputs, setpoints, and various other settings.
