Delta Controls DSC-1280 User Manual

Document Edition 2.8
Communication Ports
Ethernet
 10 BaseT @ 10Mbps
 BACnet IP, BACnet over Ethernet
NET1
 BACnet MS/TP (RS-485)
 Communication: 9600, 19200, 38400, 76800 bps (Default)
 Maximum of 99 controllers
OR
 LINKnet
 Communication: 76800 bps
 Maximum of 12 LINKnet controllers including up to two DFM
controllers
NET2
 BACnet MS/TP (RS-485)
 Communication: 9600, 19200, 38400, 76800 bps (Default)
 Maximum of 99 controllers
OR
 LINKnet
 Communication: 76800 bps
 Maximum of 12 LINKnet controllers including up to two DFM
controllers
Serial
 RS-232
 BACnet PTP
 Communication: 9600 (default), 19200, 38400
Service
Port
 RJ-11 Jack
 Used with Delta Controls service tool devices (for example,
CON-768)
Inputs
12 Universal Inputs (10 bit), jumper configurable for the following input
types:
 0-5 VDC
 0-10 VDC
 10 KΩ Thermistor
 Dry Contact (using 10 KΩ Thermistor jumper setting)
 4-20 mA
Outputs
8 Universal Outputs c/w LED status indication (including HOA status)
 0-10 VDC @ 20 mA maximum per output
 Software configurable as binary or analog
 Hand/Off/Auto Switches (c/w position feedback)
Technology
32 bit processor
2 MB (16 megabit) Flash Memory
512 KB SRAM memory
Listings
UL 916 Listed
BTL Listed (with V3.30 Release 3 firmware only)
Compliance
CE
FCC
Page 9 of 11
