EXAMPLES OF DATA DUMPING ON THE SERIAL INTERFACE
PHOTO/RADIO/THERMOMETER DATA LOGGER rev.V1 R1
IMMEDIATE SERIAL REPORT
DATE TIME ---- A --- ---- B --- ---- A-B --
16-03-2000 10:50:39 197.0 C 190.1 Lux ERR
16-03-2000 10:50:40 197.0 C 190.1 Lux ERR
16-03-2000 10:50:41 197.0 C 190.0 Lux ERR
16-03-2000 10:50:42 197.0 C 190.1 Lux ERR
Maximum Values : 197.0 C 190.1 Lux ERR
Minimum Values : 197.0 C 190.0 Lux ERR
Average Values : 197.0 C 190.0 Lux ERR
Calibration date 16-03-2000
In the above example, note the error indication for the A-B measurement, which is impossible due
to the different nature of the probes considered.
------------------------------------------------------------------------------------------------------------------------------------
PHOTO/RADIO/THERMOMETER DATA LOGGER rev.V1 R1
IMMEDIATE SERIAL REPORT
DATE TIME ---- A --- ---- B --- ---- A-B --
16-03-2000 10:54:00 112.3E3 umol/mqs 160.2 umol/mqs 112.2E3 umol/mqs
16-03-2000 10:54:01 112.3E3 umol/mqs 160.2 umol/mqs 112.2E3 umol/mqs
16-03-2000 10:54:02 112.3E3 umol/mqs 160.1 umol/mqs 112.1E3 umol/mqs
Maximum Values : 112.3E3 umol/mqs 160.2 umol/mqs 112.2E3 umol/mqs
Minimum Values : 112.3E3 umol/mqs 160.1 umol/mqs 112.1E3 umol/mqs
Average Values : 112.3E3 umol/mqs 160.1 umol/mqs 112.2E3 umol/mqs
Calibration date 16-03-2000
In the above example, note the indication E3 (= multiplier 10
3
) for the measurement of channel A,
and for the difference of the two channels. The symbol µ which is not always available on printers,
is replaced with a small letter u.
------------------------------------------------------------------------------------------------------------------------------------
108
ENGLISH
