C. Sanitizer Installation
INSTALLATION
Before starting the installation, PLEASE read this manual from cover to cover. A few moments spent
initially becoming totally familiar with the DELTA UV unit and its installation requirements will save a great
deal of time (and expense) later. If you have questions that are not answered after you have completed the
reading of this manual, contact your supplier or Delta UV. We are ready to assist you at any time and we want
your installation to go smoothly and the equipment to work properly.
LOCATING THE UV UNIT
Once you have confirmed the sizing of your pond or pool and compared that information against the
requirements of your DELTA UV unit by using the charts above, it is now time to install your unit. The
DELTA UV unit comes with all internal components fully assembled and ready for installation. Only the
Inlet/Outlet unions need to be installed to ready your unit for installation. All parts of the DELTA UV units are
UV inhibited PVC plastic. Thus, your unit will function fine in the outdoors. Installing the DELTA UV unit
indoors or inside a covered area is preferred however, to keep your unit looking new. The DELTA UV unit will
need to be directly wired. The DELTA UV unit comes with a twelve foot power cord (D/DS-5, D/DS-10
six foot cord) ready to be directly wired.
Plumbing the UV Unit: Your DELTA UV unit will need to be plumbed into your pond or swimming pool
circulation system. The diagram (Fig. 1) shows how the unit is to be plumbed. Note that the water is to be piped
from the pressure side of the pump and after the filter, in and out of the DELTA UV unit. The inlet for the water
is at the bottom of the DELTA UV unit, and the outlet is at the top of the DELTA UV unit. If your pump exceeds
the maximum flow rate of the DELTA UV unit, installation of a plumbing by-pass will be necessary to bypass
some of the pump’s flow
around the DELTA UV unit so the maximum flow rate of the DELTA UV unit will
not be exceeded. Bypass system is recommended in all installations.
●
CAUTION:
We recommend the presence of a by-pass.
Before accessing the connection terminals, ensure that all supply
circuits are disconnected.
The Sanitizer installation as a whole must be protected with a suitably
adapted circuit breaker.(See A. Technical characteristics)
Check Local ordinances and building codes before installation
of equipment. (See A. Technical characteristics)
