5
UNPACKING
Y our 50-820 Dust Collector is shipped complete in one cont ainer . Carefully remove the dust collector and all
loose p art s from the cont ainer . Figs. 2 and 3 illustrate the component s of the dust collector . W ARNING: D O N O T
CONNECT THE DUST COLLECTO R TO THE POWERSOURCE UNTIL T H E MACHINE IS COMPLETELY
ASSEMBLED AND YOU H AVE READ AND UNDERSTAND THE ENTIRE OWNER S MANUAL.
1 -Dust Collector
2 -10’ long, 4 Diameter
Vacuum Hose
3 -Dust Collector Bag
Fig. 2
Fig. 3
4 -Dust Collector Hood
5 -Clamps for T ubular
Supports (2)
6-Intake Flange
7 -Hose Clamps (2)
8 -Angled Support T ube
9 -5/16-18 x 5/8
Hex Head Screw
10 -5/16 Flat Washers (2)
11 -5/16-18 Hex Nut
12 -Upper Support Tube
2
1
3
4
5
6
12
7
8
9
11
10
