Delta AS218TX-A User Manual

 AS-FEN02
With its own standalone communication port, the extension card can work independently and can be set as a
MODBUS TCP server, Client or EtherNet/IP Adapter. After installing the extension card, go to the HWCONFIG
in ISPSoft to set up the communication.
Ethernet communication interface
Item
Specifications
Connector type
RJ-45*2
Transmission speed
10/100BASE-T (X) full duplex, switched Ethernet
Cable
CAT5e (up to 100 m)
Communication protocol
Modbus TCP Server, Client and EtherNet/IP Adapter
Isolation
1500 VAC
 AS-FOPC02
With its own standalone communication port, the extension card can work independently and can be set as a
Modbus TCP Server and OPC UA Server. After AS-FOPC02 is installed on the PLC, you need to go to
HWCONFIG to edit the parameters.
Ethernet communication interface
Item
Specifications
Connector type
RJ-45*2
Transmission speed
10/100BASE-T (X) full duplex, switched Ethernet
Cable
CAT5e (up to 100 m)
Communication protocol
Modbus TCP Server and OPC UA Server
Isolation
1500 VAC
 AS-FPFN02
With its own standalone communication port, the extension card can work independently and can be set as a
PROFINET slave to connect to PROFINET network and exchange data with PROFINET master. After
installing the extension card, go to the PROFINET Configurator to set up the communication and download
the configurations to the master and then the master sends the configurations to the function card.
Ethernet communication interface
Item
Specifications
Connector type
RJ-45*2
Transmission speed
10/100BASE-T (X) full duplex, switched Ethernet
Cable
CAT5e (up to 100 m)
Communication protocol
PROFINET RT
Isolation
1500 VAC
