 AS-FFTP01
With its own standalone communication port, the extension card can work independently and can be set as a
MODBUS TCP server, Client or EtherNet/IP Adapter. After installing the extension card, go to the HWCONFIG
in ISPSoft to set up the communication.
Ethernet communication interface
Item
Specifications
Connector type
RJ-45*2
Transmission speed
10/100BASE-T (X) full duplex, switched Ethernet
Cable
CAT5e (up to 100 m)
Communication protocol
Modbus TCP Server, Client and EtherNet/IP Adapter
Isolation
1500 VAC
Micro SD
Item Specifications
Applicalbe SD card
Micro SD card
Capacity
Max.<= 2TB (SD/SDHC/SDXC)
Speed class rating
Class 10 (C1)
Busbar interface
High Speed (25MB/s)
 It is suggested to use the Micro SD with 32GB capacity and Class10 rating
 AS-FECAT
This communication card can work independently and does NOT occupy the communication port of PLC CPU.
It can act as Modbus TCP Server and EtherCAT Master. After AS-FECAT is installed, you can go to
HWCONFIG from ISPSoft for editing in the Function Card 2 section.
Ethernet communication interface
Item
Specifications
Connector type
RJ-45*2
Transmission speed
10/100BASE-T (X) full duplex, switched Ethernet (before EtherCAT
Master enabled)
Cable
CAT5e (up to 100 m)
Communication protocol
Modbus TCP Server and EtherCAT Master
Isolation
1500 VAC
