8- ENG
D28600
2. Connect wand to gun. Tighten securely.
3. Attach high pressure hose to gun. Tighten securely.
1. Place handle assembly onto frame and connect handle to frame. NOTE:
Knobs are assembled to inside of frame.
4. To Assemble Accessories Panel
a. Remove top screws on handle assembly.
b. Loosen bottom screws on handle assembly.
Loosen
Remove
ASSEMBLY INSTRUCTIONS
To Next Page
