- 3 -
DVP
Models
Item
12SA211R 12SA211T 28SA211R 28SA211T 28SA211S
Grounding
The diameter of grounding wire cannot be smaller than the wire diameter
of terminals L and N (All DVP units should be grounded directly to the
ground pole).
Operation /
storage
Operation: 0 to 55°C (temp.), 5 to 95% (humidity), Pollution degree 2
Storage: -25 to 70°C (temp.), 5 to 95% (humidity)
Non-condensing
Vibration / shock
resistance
International standards: IEC61131-2, IEC 68-2-6 (TEST Fc)/IEC61131-2
& IEC 68-2-27 (TEST Ea)
Weight (g) 140g 131g 171g 134g 135g
Spec.
Item
Input Points
12SA2 / 28SA2 28SA2
Input No.
X0 ~ X2 (12SA2)
X0 ~ X3 (28SA2)
X3 ~ X7 (12SA2)
X4 ~ X7 (28SA2)
X10~X17
Input type DC (SINK or SOURCE)
Input current（±10%） 24 VDC，5 mA
Input impedance 4.7 kΩ
Max. frequency 100 kHz 10 kHz 50Hz
Action level
Off On > 15 VDC
On Off < 5 VDC
Response
time
Off On < 2.5 μs < 20 μs <10ms
On Off < 5 μs < 50 μs <10ms
Filter time Adjustable within 0 ~ 20ms by D1020 (Default: 10ms)
Spec.
Item
Output Points
Relay Transistor (NPN & PNP)
Output No. Y0 ~ Y3 Y0, Y2 Y1, Y3 Y10~Y13
Max. frequency 1 Hz 100 kHz 10 kHz
1kHz
#5
Working voltage
100~250 VAC, 5~30 VDC
#4
5 ~ 30 VDC
#1
Leak current
–
<100uA
Max. load
Resistive
1.5 A /1 point（5 A/COM） 0.5 A/1 point（4 A/COM）
Inductive
#2
15 W（30 VDC）
Lamp 20 WDC/100 WAC
2.5 W（30 VDC）
Min. load 1mA / 5V 1mA/5V
Response
time
Off On
Approx. 10 ms
2 μs
#3
20 μs
#3
100μs
#3
On Off
3 μs
#3
30 μs
#3
100μs
#3
#1: UP, ZP must work with external auxiliary power supply 24 VDC (-15 to +20%), rated
consumption approx. 1mA/point.
#2: Relay contact life can be influenced by operating voltage , load types(cosø/ t) and contact
current rating. Figure 2 below shows the number of operations for reference.
Contact
current(A)
0.5
0.1
0.2
50
0.3 0.7
12
200
300
500
100
1,000
2,000
3,000
O
p
e
r
a
t
i
o
n
(
X
1
0
)
3
120 VAC, resistive
30 VDC, inductive (t=7ms)
240 VAC, inductive (cos 0.4)
ψ
=
120 VAC, inductive (cos =0.4)
ψ
30 VDC,
inductive
(t=40ms)
[ Figure 2 ]
