Delta DVP-SA2 Instruction Sheet

- 4 -
#3: Load = 0.5A
#4: The max. Output speed is influenced by the actual PLC scan time.
 I/O Configuration
12SA211R 12SA211T 28SA211R 28SA211T 28SA211S
Relay
8IN/4OUT
Transistor (NPN)
8IN/4OUT
Relay
16IN/12OUT
Transistor (NPN)
16IN/12OUT
Transistor (PNP)
16IN/12OUT
DC (Sink or Source)

S/S
X0
X1
X2
X3
X4
X5
X6
X7

C0
Y0
Y1
Y2
●
SG
CO M 3+
Y3
CO M 3-

S/S
X0
X1
X2
X3
X4
X5
X6
X7

Y0
Y1
Y2
SG
CO M 3+
Y3
COM3-
UP
ZP

S/S
X0
X1
X2
X3
X4
X5
X6
X7

S/S
X0
X1
X2
X3
X4
X5
X6
X7
Note: The layout of output terminals on DVP-SA2 is different from that on DVP-SA.
 Dimension & Installation
Please install the PLC in an enclosure with sufficient
space around it to allow heat dissipation, See
[Figure 3].
 Direct Mounting: Use M4 screw according to the
dimension of the product.
 DIN Rail Mounting: When mounting the PLC to
35mm DIN rail, be sure to use the retaining clip to
stop any side-to-side movement of the PLC and
reduce the chance of wires being loose. The retaining clip is at the bottom of the PLC.
To secure the PLC to DIN rail, pull down the clip, place it onto the rail and gently push
it up. To remove the PLC, pull the retaining clip down with a flat screwdriver and gently
remove the PLC from DIN rail.
 Wiring
1. Use 26-16AWG (0.4~1.2mm) single or multiple core wire

2
6
-
1
6
A
W
G
0
.
4
~
1
.
2
m
m
on I/O wiring terminals. See the figure in the right hand
side for its specification. PLC terminal screws should be
tightened to 2.00 kg-cm (1.77 in-lbs) and please use only
60/75ºC copper conductor.
2. DO NOT wire empty terminal. DO NOT place the I/O signal cable in the same wiring
circuit.
3. DO NOT drop tiny metallic conductor into the PLC while screwing and wiring. Tear
off the sticker on the heat dissipation hole for preventing alien substances from
dropping in to ensure normal heat dissipation of the PLC.
