Delta DVP-SA2 User Manual

3. Instruction Set
3-23
Mnemonic : Indicates the name and the function of the instruction
Operand
: The parameter setting for the instruction
Source: if there are more than one source is required, it will be indicated as S
1
, S
2.
...etc.
Destination: if there are more than one destination is required, it will be indicated as D
1
,
D
2.
...etc.
If the operand can only be constant K/H or a register, it will be represented as m, m
1
, m
2
, n, n
1
,
n
2
…etc.
Length of Operand (16-bit or 32-bit instruction)
The length of operand can be divided into two groups: 16-bit and 32-bit for processing data of
different length. A prefix ”D” indicates 32-bit instructions.
16-bit MOV instruction
X0
K10
D10
MOV
When X0 = ON, K10 will be sent to D10.
32-bit DMOV instruction
X1
D10 D20
DMOV
When X1 = ON, the content in (D11, D10) will be
sent to (D21, D20).

Delta DVP-SA2 Specifications

General

Series	DVP
Model	DVP-SA2
Type	PLC
Input Voltage	24V DC
Number of Inputs	16
Number of Outputs	16
Communication Ports	RS-232, RS-485
Programming Language	Ladder Diagram
Operating Temperature	0°C to 55°C
Digital Input	16
Digital Output	16 points
High-Speed Counter	Yes
Pulse Output	Yes
I/O Points	32
Storage Temperature	-25°C to 70°C
Humidity	5% to 95% (non-condensing)
