Delta DVP-SA2

3. Instruction Set
3-225
Compared counter result 2 of the object when entering
(32-bit)
K6600 K
7620 K8630
Device D number D2024 D2026 D2028
Compared counter result 2 of the object when leaving
(32-bit)
K7050 K
7980 K9020
Device D number D2030 D2032 D2034
Compared counter result 3 of the object when entering
(32-bit)
K0 K0 K0
Device D number D2036 D2038 D2040
Compared counter result 3 of the object when leaving
(32-bit)
K0 K0 K0
The following table shows the state of the output point Y when the high-speed counter C251
reaches 5200.
Output point Y number Y0 Y1 Y2
16-bit value ON OFF OFF
Device D number D2000 D2001 D2002
Value of the head index (16-bit) K4 K4 K4
Device D number D2003 D2004 D2005
Value of the tail index (16-bit) K2 K1 K1
The following table shows the state of the output point Y when the high-speed counter C251
reaching 6200.
Output point Y number Y0 Y1 Y2
16-bit value OFF ON OFF
Device D number D2000 D2001 D2002
Value of the head index (16-bit)
K4 K4 K4
Device D number
D2003 D
2004 D2005
Value of the tail index (16-bit)
K3 K2 K1
